型號	光敏尺寸	響應波長-峰值	響應度-峰值	暗電流	電容	封裝	封裝類型	窗口	引腳數
SG01D-C5D	0.5mm2	275 nm	0.02A/W	1.7 fA@-1V	125 pF	TO-5	TO	Diffusor	2
SG01D-C5ISO90	0.5mm2	275 nm	0.160A/W	1.7 fA@-1V	125 pF	TO-5	TO	-	3
SG01D-C5LENS	0.5mm2	275 nm	0.160A/W	1.7 fA@-1V	125 pF	TO-5	TO	Lens	2
SG01D-C18	0.5mm2	275 nm	0.160A/W	1.7 fA@-1V	125 pF	TO-18	TO	-	2
SG01D-C18ISO90	0.5mm2	275 nm	0.160A/W	1.7 fA@-1V	125 pF	TO-18	TO	-	3
SG01F-C5	1.82mm2	275 nm	0.160A/W	6 fA@-1V	455 pF	TO-5	TO	-	2
SG01L-C5	1.0mm2	275 nm	0.160A/W	3.3 fA@-1V	250 pF	TO-5	TO	-	2
SG01L-C5D	1.0mm2	275 nm	0.02A/W	3.3 fA@-1V	250 pF	TO-5	TO	Diffusor	2
SG01L-C18	1.0mm2	275 nm	0.160A/W	3.3 fA@-1V	250 pF	TO-18	TO	-	2
SG01M-C5	0.2mm2	275 nm	0.160A/W	0.7 fA@-1V	50 pF	TO-5	TO	-	2
SG01M-C5D	0.2mm2	275 nm	0.02A/W	0.7 fA@-1V	50 pF	TO-5	TO	Diffusor	2
SG01M-C5ISO90	0.2mm2	275 nm	0.160A/W	0.7 fA@-1V	50 pF	TO-5	TO	-	3
SG01M-C18	0.2mm2	275 nm	0.160A/W	0.7 fA@-1V	50 pF	TO-18	TO	-	2
SG01M-C18ISO90	0.2mm2	275 nm	0.160A/W	0.7 fA@-1V	50 pF	TO-18	TO	-	3
SG01S-C5	0.06mm2	275 nm	0.160A/W	0.2 fA@-1V	15 pF	TO-5	TO	-	2
SG01S-C18	0.06mm2	275 nm	0.160A/W	0.2 fA@-1V	15 pF	TO-18	TO	-	2
SG01S-C18D	0.06mm2	275 nm	0.02A/W	0.2 fA@-1V	15 pF	TO-18	TO	Diffusor	2
SG01S-C18ISO90	0.06mm2	275 nm	0.160A/W	0.2 fA@-1V	15 pF	TO-18	TO	-	3
SG01S-C18ISO90D	0.06mm2	275 nm	0.02A/W	0.2 fA@-1V	15 pF	TO-18	TO	Diffusor	3
SG01XL-C5	7.6mm2	275 nm	0.160A/W	25.3 fA@-1V	900 pF	TO-5	TO	-	2
SG01S-C18-LED	0.06mm2	285 nm	0.160A/W	0.2 fA@-1V	15 pF	TO-18	TO	-	2
SG01D-C18D	0.5mm2	275 nm	0.02A/W	1.7 fA@-1V	125 pF	TO-18	TO	Diffusor	2
