型號	光敏尺寸	暗電流	上升沿時間	反向擊穿電壓	溫度系數-擊穿電壓	封裝	封裝類型	引腳數	窗口
SAE230NF3	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	3	Filter
SAE230NL3	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	3	Lens
SAE230NM8	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic SMD	SMD	8	-
SAE230NM8F	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic SMD	SMD	8	Filter
SAE230NS2	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	2	-
SAE230NS3	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	3	-
SAE230NT6	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-37	TO	6	-
SAE230NY1	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic Submount	Special	2	-
SAE230NY2	?230 μm	0.5 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic Submount	Special	2	-
SAE500NF3	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	3	Filter
SAE500NL3	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	3	Lens
SAE500NM8	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic SMD	SMD	8	-
SAE500NM8F	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic SMD	SMD	8	Filter
SAE500NS2	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	2	-
SAE500NS3	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-46	TO	3	-
SAE500NT6	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	TO-37	TO	6	-
SAE500NY1	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic Submount	Special	2	-
SAE500NY2	?500 μm	1.0 nA@M=100	0.5 ns@M=100	150 … 300V@10μA	0.9V/K	Ceramic Submount	Special	2	-
